Trunnion Three Piece Design Ball Valve Reduce or Full Bore (Gear Operated)

A trunnion three-piece design ball valve with gear operation is a high-performance valve designed for precise flow control in critical industrial applications. It features a trunnion-mounted ball that is securely supported at both ends, reducing operational torque and ensuring reliable sealing under high-pressure conditions. The three-piece construction allows for easy disassembly, maintenance, and replacement of parts without removing the entire valve from the pipeline. Available in reduced bore for cost efficiency or full bore for unrestricted flow, it caters to various operational needs. The gear-operated mechanism ensures smooth and effortless control, especially in large or high-pressure systems. Commonly used in industries like oil and gas, petrochemicals, and power generation, this valve is valued for its durability, efficiency, and ease of operation in demanding environments.

Details

Specifications

Design std

API 6D BS 5351 / ISO5211

Size

2″ TO 24″

CLASS

150# TO 1500#

Body Material

WCB, CF8, CF8M.

END PIECE

WCB, CF8, CF8M.

BALL

A105+ENP13%CR, CF8, CF8M, ETC.

SEAT MATERIALS

PTFE, PRTFE, NYLON, DEVLON, PEEK, METAL TO METAL

FACE TO FACE

ANSI B16.10

END CONNECTION

ANSI B16.5 RF ANSI B16.25
