Floating Two Piece Design Ball Valve Reduce or Full Bore (Gear Operated)

A floating two-piece design ball valve with gear operation is a reliable valve designed for efficient flow control in industrial applications. The floating ball ensures a secure seal by pressing against the valve seat under pressure, preventing leaks. The two-piece construction allows for easier assembly, disassembly, and maintenance, enhancing its practicality. Available in reduced bore for cost efficiency or full bore for unrestricted flow, it is suitable for a variety of applications. The gear-operated mechanism provides smooth and effortless operation, especially for larger valves or high-pressure systems. This valve is commonly used in industries such as oil and gas, petrochemical, and water treatment, valued for its durability, precision, and ease of operation.

Details

Specifications

Design std

BS 5351 / ISO5211

Size

½” TO 12″

CLASS

150# 300# 600#

Body Material

WCB, CF8, CF8M.

END PIECE

WCB, CF8, CF8M.

BALL

A105+ENP13%CR, CF8, CF8M, ETC.

SEAT MATERIALS

PTFE, PRTFE, NYLON, DEVLON, PEEK, METAL TO METAL

FACE TO FACE

ANSI B16.10

END CONNECTION

ANSI B16.5 RF ANSI B16.25 BW
